| Model | VMC 1160 |
| Working area | |
| Table size | 1200x600 mm |
| Table load capacity | 900 kg |
| T-slot (number/width/distance) | 5/18/100 mm |
| Spindle nose to table surface distance | 120-720 mm |
| Spindle to coloum distance | 610 mm |
| Travel | |
| Travel X-aixs | 1100 mm |
| Travel Y-aixs | 600 mm |
| Travel Z-aixs | 600 mm |
| Headstock | |
| Spindle speed | 8000 rpm |
| Spindle taper | BT 40 |
| Feed speed | |
| Rapid feed X-axis | 36000 mm/min |
| Rapid feed Y-axis | 36000 mm/min |
| Rapid feed Z-axis | 36000 mm/min |
| Work feed | 1-10000 mm/min |
| Tool head | |
| Number of tool station | 24 T |
| Tool station type | Arm |
| Diameter of tool | 78 mm |
| Tool length (max) | 300 mm |
| Tool weight (max) | 8 kgs |
| Tool changing time | 2.3 sec |
| Accuracy | |
| Positioning accuracies | ±0.005 mm |
| Repeatable positioning accuracies | ±0.003 mm |
| Drive Capacity | |
| Main motor | 11 kw |
| X-axis servo motor | 3.0 kw |
| Y-axis servo motor | 3.0 kw |
| Z-axis servo motor | 3.0 kw |
| Total power consumption | 25 kw |
| Ball screws and Linear | |
| Diameter of X/Y/Z axis ball screws | Φ40 |
| Linear guideway width/guideway number/block number-X axis | 45/2/6 |
| Linear guideway width/guideway number/block number-Y axis | 45/2/4 |
| Linear guideway width/guideway number/block number-Z axis | 45/2/6 |
| Shipping information | |
| Net weight | 5500 kg |
| Machine working dimension | 3140x2280x2620 mm |
| Packing size | 3180x2300x2540 mm |
| Coolant tank capacity | 280 L |
| Standard accessories (Brand) | |
| Siemens 828D control system | |
| Schneider electrical units | |
| Spindle (Taiwan - Kenturn or Volis) | |
| Arm tool station (Taiwan - Okada or Relib) | |
| Linear guideway (Taiwan - Hiwin or PMI) | |
| Ball screws (Taiwan - Hiwin or PMI) | |
| Bearing (Janpan - Koyo) | |
| Pneumatic parts (Taiwan - Mindman) | |
| Screw conveyor | |
