BS-200S
Feature:
· The saw is a compact and quality type for DRY and professional user
· Four speed setting via belt change
· Cutting angle settings -45° ~ +45°
· Workpiece fence for economic work
· Copper brush to clear the chips
· Automatic shut-down at cutting end
· Cutting pressure adjustable via valve
· Precise and stable saw blade guides ensure high angular accuracy
· CE magnetic switch for safety operation
· Equipped with coolant system, stand
MESSAGE
ModelBS-200S
Cutting capacity round 0°205mm
Cutting capacity flat 0°230x205mm
Cutting capacity round 45° R135mm
Cutting capacity flat 45° R135x125mm
Cutting capacity round 45° L160mm
Cutting capacity flat 45° L160x205mm
Working height810mm
Sawing angle-45° ~ +45°
Cutting speed24/41/61/82m/min
Bandsaw blade dimension2360x20x0.9mm
Main drive structureBelt
Vise clampingManual
Blade tensionManual
Band saw blade cleaning methodbrush
Motor power1.1kw
Coolant pump40w
Coolant13L
Net weight190kg
Gross weight217kg
Machine dimension1200x625x1240mm
Packing size1230x650x820mm/580x550x260mm
Standard accessories:Optional accessories:
Saw bladeRoller stand
Workpiece fenceCE elecctrical box and 24 control wiring
Hydraulic cylinder
Coolant system
Stand
